A DMM for voltage is a digital multimeter whose main job is reading volts, AC or DC, with the current and resistance functions as extras. This guide compares five pocket and bench-style meters from the listing data, using the count, the voltage ranges, the safety rating and the power details each listing gives. Where two figures in one listing disagree, both are shown. Listing figures were checked on 11 and 13 October 2026.
Quick answer: for the widest listed AC voltage span, the UNI-T UT133A gives 600 V AC with a CAT III 600 V rating. For a pocket meter with a 1999 maximum reading, the allsun mini and the AIOMEST are the smallest listings here. The AstroAI is the 2000-count option with a 10 A fuse.
The five meters at a glance
| Meter | Count (as listed) | AC voltage (as listed) | Rating (as listed) |
|---|---|---|---|
| AstroAI 2000-count (B01ISAMUA6) | 2000 | 200 V and 600 V | CAT II 600 V, CAT III 300 V |
| UNI-T UT133A (B099RY58CT) | 6000 | 600 V | CAT III 600 V |
| AIOMEST AI-4201 (B088RFWBKD) | Not stated | 1 mV to 450 V (AC and DC) | Not stated |
| allsun Mini Folding (B07RHDVTQG) | 1999 maximum | Not stated | Not stated |
| LJPXHHU 2000-count (B0CXM242J1) | 2000 | Not stated | Not stated |
How we chose these five
We kept meters whose listing states a voltage function and a count or range. The keyword is a short name for a voltage meter, so the set covers the product type rather than any one brand. We did not test any of these meters, and nothing below reports personal use.
- Voltage range: the AC and DC span each listing gives.
- Count: the display resolution, where the listing states it.
- Rating: the CAT category, where the listing states one.
1. AstroAI 2000-Count Digital Multimeter (B01ISAMUA6)
The AstroAI is a 2000-count meter, with DC voltage ranges of 200 mV, 2 V, 20 V, 200 V and 600 V, and AC voltage ranges of 200 V and 600 V. The listing gives DC voltage accuracy as plus or minus 0.5 percent plus 3 digits. Its listing is in conflict on sampling speed: the specification table says 3 times per second, while a bullet says 2 times per second, so check the figure on the product page. It takes two 1.5 V AAA batteries and has a 10 A fuse for current. Check the AstroAI meter on Amazon.
2. UNI-T UT133A Digital Multimeter (B099RY58CT)
The UT133A is listed at 6000 counts with auto ranging. It measures AC volts up to 600 V, DC volts up to 600 V and AC current up to 10 A. Its listing adds resistance, capacitance, frequency, temperature from minus 40 to 1000 degrees Celsius, a continuity buzzer, a diode test and an NCV function. The bullets give a CAT III 600 V rating, an overload alarm and a built-in kickstand. Check the UT133A on Amazon.
3. AIOMEST AI-4201 Pocket Digital Multimeter (B088RFWBKD)
The AIOMEST is a card-sized meter. Its listing gives DC and AC voltage from 1 mV to 450 V and resistance from 100 mΩ to 40 MΩ, with a continuity buzzer and auto ranging. The bullets say it comes with a leather protective case, and they describe it for low-voltage work for DIYers and mechanics. The listing does not give a count or a CAT rating. Check the AIOMEST meter on Amazon.
4. allsun Mini Folding Digital Multimeter (B07RHDVTQG)
The allsun is a folding pocket meter with a 3 and a half digit LCD and a maximum reading of 1999. Its bullets list auto range, data hold, low battery indication, overrange indication and a negative polarity indicator, plus DC and AC volts, AC and DC amps, ohms, a diode test and continuity with a tone. Its listing does not give a voltage span or a CAT rating. Check the allsun meter on Amazon.
5. LJPXHHU 2000-Count Digital Multimeter (B0CXM242J1)
The LJPXHHU is a 2000-count meter with a 2.7-inch backlit LCD. Its listing covers AC and DC voltage, DC current, resistance, continuity, diode and battery tests, with overload protection on all ranges. The bullets say it has a data hold and a low-battery indication. The listing gives no voltage span or CAT rating in the data we hold. Check the LJPXHHU meter on Amazon.
Worked example: a 120 V outlet check
For example, take a 120 V outlet read on AC volts. The AstroAI’s 200 V AC range covers it, and the 600 V range is the next step up. The UT133A’s 600 V AC range also covers it, with more headroom. The AIOMEST lists AC up to 450 V, so it covers 120 V as well. The allsun and LJPXHHU listings do not state an AC voltage span, so their coverage of 120 V cannot be checked from the listing data.
What the listings do not say
Most of these listings give no accuracy for the AC voltage range, so the comparison cannot rank precision. One AstroAI bullet says the meter cannot test all AC current and AC voltage below 100 mV, and that a reading needs the leads and rotary switch set correctly. Check the manual before a job that involves mains.
Frequently asked questions
Which meter has the widest AC voltage range listed?
The UT133A is listed at 600 V AC, and the AstroAI also lists 600 V AC. The AIOMEST is listed at up to 450 V AC and DC.
What does a 2000-count meter read?
A 2000-count meter shows up to 1999 on its display before it overranges. The AstroAI and LJPXHHU are both listed at 2000 counts, and the allsun at a 1999 maximum reading.
Which meter is the smallest?
The AIOMEST is described as card-sized, and the allsun as a folding pocket meter. Both are the most compact listings here.
Does the AstroAI listing disagree with itself?
On one figure, yes. Its specification table gives a sampling speed of 3 times per second, and a bullet gives 2 times per second. Confirm the figure on the product page.
How current are these listing figures?
The listings were checked on 11 and 13 October 2026, and figures are shown as the sellers state them. Confirm the range on the product page before you buy.
Conclusion
For AC voltage, the UT133A lists the widest span and a CAT III 600 V rating. The AIOMEST covers up to 450 V and suits a pocket. The AstroAI and LJPXHHU are both 2000-count meters, and the AstroAI lists its 10 A fuse. Match the range to the voltage you test, and check each product page for the figures the listing leaves out.
