A voltage detector pen tells you whether AC voltage is present near a wire or outlet, and the listing states the lowest voltage it will alarm on and the highest it covers. Those two numbers, plus the safety rating, are what separate the pens in this group. The brand named in the search does not appear among the listings we checked, so this post compares six voltage detector pens from the set. Research figures were checked on 11 October 2026, and the newer pens on 18 October 2026.
Quick answer: for the lowest floor on a pen with two settings, the focemta kit and the X-XIANQI two-pack both list 12V on their high setting. For a single 50V to 1000V pen with an always-on design, look at the Santronics 3000. For a dual-range pen with a 600V top, the Southwire 40126N is the one to compare.
The six pens at a glance
| Pen | Range (as listed) | Settings | Rating (as listed) | Size and weight (as listed) |
|---|---|---|---|---|
| Santronics 3000 (B008M6YLF4) | 50V-1000V AC | Single range, always on | CAT IV (bullet) | 5.58 x 0.5 x 0.75 inches, 46.2 g |
| Southwire 40126N (B01M9B2AH9) | 24V-600V AC | Dual range (title) | Cat IV 600V | 1 x 1 x 1 inches, 2.56 ounces |
| focemta FTVT01 kit (B0H9RJ8DF2) | 12V-1000V and 48V-1000V | High and low settings | CE CAT III 1000V, CAT IV 600V | Not given |
| X-XIANQI AC001 two-pack (B0D7YT44NN) | 12V-1000V and 48V-1000V | S button, high and low | CE, RoHS; CAT III 600V in a bullet | Not given |
| Weikani VT120 (B09224B5ZZ) | 60V-1000V AC | Single range | CAT IV, ETL, CE (bullet) | Item weight 9.07 g |
| Sperry VD7504GFI (B0152U89DC) | 50V-1000V in the title, 50V-600V in a bullet | Combined with a GFCI tester | CAT III 1000V (bullet) | 8.4 x 3.7 x 0.6 inches |
How we chose these six
We kept pens whose listing states a detection range and a rating, and we chose a spread of floors and tops so that the set shows the differences clearly. Three of the six are newer listings, and the other three are research items: the Santronics, the Southwire and the Sperry. To keep the picks distinct from the other pens on this site, we set aside the Neoteck, VENLAB, MXCOIRTP, Klein and zangang pens. The DMwespe two-pack repeats the MXCOIRTP wording, the Zoyi DB02 repeats the dual range of the focemta and X-XIANQI, and the Westinghouse pen gives a title range and a bullet range that do not agree.
- Range: the detection range the listing states, with conflicts shown side by side.
- Settings: whether the pen has one range or a choice of two.
- Rating: the CAT or safety mark in the specs field or bullets, as written.
1. Santronics 3000 Non-Contact Voltage Tester
The Santronics 3000 has no on or off switch, so it is ready to check as soon as you take it from a pocket. Its title and bullets give AC detection from 50 to 1000 volts, and the bullets say a high-intensity LED and an audible beep both fire when voltage is detected. The listing says the body is high-impact polycarbonate that meets CAT IV standards for industrial and commercial use. The bullets say the pen is made in the USA, but the listing gives no test figure for its sensitivity. The item weighs 46.2 g and measures 5.58 x 0.5 x 0.75 inches.
Check the Santronics 3000 on Amazon
2. Southwire 40126N Dual Range Voltage Pen
The Southwire 40126N is listed as a dual-range NCV pen for 24V to 600V AC, and its specs field gives the same style name. The specs field gives the rating as Cat IV 600V and a warranty of 2 years. The bullets say the pen gives audible and visual alerts, has two flashlights, and shuts off automatically to save the battery. The pen runs on AAA batteries. The item dimensions field reads 1 x 1 x 1 inches, which is not a full pen size, so check the length on the package. The item weighs 2.56 ounces.
Check the Southwire 40126N on Amazon
3. focemta FTVT01 Voltage Tester and GFCI Kit
The focemta kit combines a voltage pen and a GFCI outlet tester. The pen is listed for 12V to 1000V and 48V to 1000V AC, with a high and a low setting. The specs field gives the rating as CE CAT III 1000V and CAT IV 600V. The GFCI tester is listed for 90V to 135V AC, and the bullets say it works by direct plug-in rather than by non-contact detection. The indicator lights on the GFCI tester show the wiring status, and the kit includes two AAA batteries according to the bullets.
Check the focemta FTVT01 kit on Amazon
4. X-XIANQI AC001 Non-Contact Voltage Tester Two-Pack
The X-XIANQI AC001 comes as a two-pack in orange. Its highlight gives a dual range of 12V to 1000V and 48V to 1000V AC, and the bullets say the S button switches between high and low sensitivity. The listing suggests the low setting for thermostats, irrigation wires and doorbells. The specs field gives CE and RoHS marks, and one bullet gives CE CAT III 600V. The pen has an LED flashlight, a buzzer, a low-power indicator below 2.5V and an automatic power-off after 3 minutes without operation or a detected signal. The listing gives 36-month after-sale service and includes two batteries.
Check the X-XIANQI AC001 two-pack on Amazon
5. Weikani VT120 Voltage Detector Pen
The Weikani VT120 is a single-range pen for 60V to 1000V AC. Its specs field gives a minimum operating voltage of 60 volts, and the bullets say it detects 60V to 1000V AC. The safety bullet lists CAT IV, ETL and CE, and it advises against placing the tip directly into a power supply and recommends gloves. The detection light flashes red and the buzzer sounds short beeps when AC voltage is detected. The bullets give 36-month after-sale service, while the specs field gives a 3-year EU spare part availability period. Those are two different terms, so read each one as it is written. The specs field gives an item weight of 9.07 g.
Check the Weikani VT120 on Amazon
6. Sperry VD7504GFI Voltage Detector and GFCI Tester
The Sperry VD7504GFI combines a non-contact voltage detector with a GFCI outlet tester at its other end. Its title gives a range of 50V to 1000V AC, but a bullet gives 50V to 600V AC for the same detection. The bullets give a rating of CAT III 1000V, a 10 ft drop rating and a 250 lb crush rating. The listing describes a 360-degree visual indicator with a beeping audio alert. The specs field gives a size of 8.4 x 3.7 x 0.6 inches and lists the maker as Actuant. Check which top figure applies before you rely on the pen for a source above 600 volts.
Check the Sperry VD7504GFI on Amazon
Worked example: which pens cover a 30 volt AC source?
Take a source that reads 30V AC. The focemta high setting starts at 12V, so it covers 30V. The focemta low setting starts at 48V, so it does not. The X-XIANQI high setting also covers 30V, and its low setting does not. The Southwire 24V to 600V range covers 30V. The Santronics starts at 50V, the Weikani at 60V, and the Sperry title and bullet both start at 50V, so none of those three covers 30V.
Now take a 700 volt AC source. The Southwire tops out at 600V, so it does not cover 700V. The Santronics and the Weikani both reach 1000V, so both cover 700V. The Sperry title covers 700V, but its bullet stops at 600V. For that one source, the Sperry listing does not give a single answer, so check the figure on the box before you use it.
These examples use only the floors and tops the listings state. They do not show how each pen responds near its floor, and the listings do not compare them side by side.
What the listings do not say
None of the listings reports an independent test of its detection range or its rating. The Santronics listing describes its sensitivity without a test figure, and the Sperry listing gives two different top figures. The Southwire listing gives a dual range in its title but no second range figure in the bullets. The focemta and X-XIANQI listings both start their low setting at 48V, and neither gives a lower figure for it. Check the range, the rating and the warranty on the package before you buy.
Frequently asked questions
Do I need a pen with a dual range?
A dual range lets you choose a lower floor for thin or low-voltage wiring, such as thermostat or doorbell lines. The focemta and X-XIANQI listings both give a 12V high setting and a 48V low setting. A single-range pen such as the Weikani, which starts at 60V, will not alarm on a low source at all.
Which pen has the highest listed top?
The Santronics, the focemta, the X-XIANQI and the Weikani all list a top of 1000V AC. The Southwire lists 600V, and the Sperry title lists 1000V while one bullet lists 600V.
Is the GFCI tester in the kits a voltage pen?
No. The focemta listing says its GFCI tester works by direct plug-in, not by non-contact detection, and the Sperry listing describes its GFCI tester on the other end. Use the GFCI tester for outlet wiring checks, and use the pen for non-contact voltage.
How long do these pens stay on?
The X-XIANQI listing gives an automatic power-off after 3 minutes without operation or a detected signal. The Santronics has no on or off switch, and the other listings in this post do not give an auto-off time in the fields we read.
Can a voltage pen confirm a circuit is dead?
No listing in this set says a pen confirms that a circuit is dead. Use the pen as a first check, and confirm with a separate tester before you work on a circuit.
Conclusion
For the lowest floor on a two-setting pen, the focemta kit and the X-XIANQI two-pack both list 12V on the high setting, and the X-XIANQI adds the 48V low setting for thermostat and doorbell wires. For a single 50V to 1000V pen, the Santronics 3000 is the one to look at. For a dual-range pen with a 600V top, the Southwire 40126N fits. Compare each listed range with the source you test, and read the rating on the pen itself. For related reading, see best AC voltage detector, best NCV tester, best non-contact voltage checker, and best wall socket tester.
